Palancole

Scatola doppia

profilio Dimensioni Ambito Area peso Momento d’inerzia Momento resistente Raggio di curvatura minimo Superficie di rivestimento
Tavola singola Scatola
B H y-y z-z y-y z-z
mm mm cm cm2 cm2 kg/m cm4 cm4 cm3 cm3 cm m2/m
VL601 632 348 188 118,0 1593 92,6 18229 48407 1047 1532 12,43 1,61
VL601FP 632 348 188 120,8 1593 94,8 18310 50222 1052 1589 12,31 1,61
VL601K 632 349 188 123,5 1597 97,0 19119 50563 1096 1600 12,44 1,61
VL602A 633 350 188 130,7 1603 102,6 19987 54270 1144 1715 12,37 1,61
VL602 633 350 188 136,0 1608 106,8 20976 56067 1197 1771 12,42 1,61
VL602K 633 351 188 141,2 1613 110,8 21968 57872 1251 1828 12,47 1,62
VL603A 637 362 201 156,7 1823 123,0 28925 68300 1598 2144 13,59 1,74
VL603 637 363 202 163,6 1831 128,4 30718 70370 1692 2209 13,70 1,74
VL603KN 638 365 202 170,4 1844 133,8 31872 74292 1747 2329 13,68 1,74
VL603K 638 365 202 172,7 1844 135,6 32180 75576 1764 2369 13,65 1,74
VL603N 635 466 206 152,2 2096 119,4 40904 62667 1756 1974 16,39 1,79
VL603Z 638 369 202 183,7 1864 144,2 34350 81479 1863 2554 13,67 1,75
VL604A 638 435 214 181,0 2178 142,0 46946 80555 2161 2525 16,10 1,86
VL604 638 435 214 186,3 2180 146,2 48661 82354 2238 2582 16,16 1,86
VL604K 638 436 214 191,7 2185 150,4 50437 84288 2316 2642 16,22 1,87
VL605A 638 465 218 194,9 2299 153,0 58035 84324 2497 2643 17,26 1,90
VL605N 638 467 219 209,2 2313 164,2 64607 87814 2764 2753 17,57 1,91
VL605KN 638 469 219 218,1 2321 171,2 67950 90864 2898 2848 17,65 1,91
VL606A 638 475 219 217,6 2340 170,8 71383 87654 3006 2748 18,11 1,92
VL606AN 638 477 220 228,7 2351 179,6 76538 90482 3210 2836 18,29 1,92
VL606N 638 479 220 239,7 2362 188,2 81740 93307 3414 2925 18,47 1,93
VL606K 638 477 220 246,2 2351 193,2 84585 93502 3547 2931 18,54 1,92
VL606KN 638 479 220 260,6 2366 204,6 90579 98184 3783 3078 18,64 1,93
VL628-1,5 638 498 223 242,4 2428 190,4 88077 95257 3540 2986 19,06 1,91
VL628AN 638 499 224 249,3 2435 195,8 91441 97116 3666 3044 19,15 1,91
VL628A 638 500 224 256,8 2442 201,6 95320 98967 3811 3102 19,27 1,91
VL628 638 501 224 259,3 2445 203,6 96749 99740 3854 3127 19,29 1,91
VL628K 638 501 224 263,7 2449 207,0 98722 100830 3938 3161 19,35 1,91
VL607A 638 499 222 270,7 2430 212,4 100704 101843 4033 3193 19,29 1,95
VL607 638 502 223 286,3 2445 224,8 105163 109326 4190 3427 19,17 1,97
VL607K 638 504 223 297,5 2457 233,6 108118 114994 4290 3605 19,06 1,96



spundbohle-produkte-spundbohlenfaehle-dreifachbox

Palancole

Scatola tripla

profilio Dimensioni Ambito Area peso Momento d’inerzia Momento resistente Raggio di curvatura minimo Superficie di rivestimento
Tavola singola Scatola
B H y-y z-z y-y z-z
mm mm cm cm2 cm2 kg/m cm4 cm4 cm3 cm3 cm m2/m
VL601 745 724 278 177,0 4035 138,9 111704 111704 3000 2999 25,12 2,41
VL601FP 745 724 278 181,2 4035 142,2 114291 114291 3070 3068 25,11 2,41
VL601K 745 725 278 185,3 4040 145,5 116954 116954 3140 3138 25,12 2,41
VL602A 747 726 279 196,1 4054 153,9 123978 123978 3322 3321 25,14 2,42
VL602 747 727 279 204,0 4062 160,2 129056 129056 3457 3454 25,15 2,42
VL602K 748 727 279 211,8 4070 166,2 134138 134138 3591 3587 25,17 2,42
VL603A 817 735 298 235,0 4395 184,5 160165 160165 4258 3923 26,11 2,60
VL603 818 737 299 245,3 4407 192,6 167522 167522 4450 4097 26,13 2,61
VL603KN 820 739 299 255,6 4431 200,7 175086 175086 4641 4271 26,17 2,61
VL603K 820 739 299 259,1 4431 203,4 177531 177531 4706 4331 26,18 2,61
VL603N 847 786 306 228,3 4803 179,1 171128 171128 4158 4042 27,38 2,66
VL603Z 823 741 300 275,6 4459 216,3 189690 189690 5022 4612 26,24 2,62
VL604A 879 773 317 271,5 4933 213,0 207010 207010 5223 4709 27,61 2,80
VL604 879 773 317 279,4 4936 219,3 213276 213276 5379 4850 27,63 2,80
VL604K 880 774 318 287,5 4943 225,6 219765 219765 5538 4995 27,65 2,80
VL605A 899 789 324 292,4 5115 229,5 232134 232134 5641 5165 28,18 2,86
VL605N 901 791 324 313,8 5136 246,3 251195 251195 6085 5573 28,29 2,87
VL605KN 902 791 325 327,1 5148 256,8 262422 262422 6346 5817 28,32 2,87
VL606A 906 794 326 326,4 5176 256,2 264870 265870 6359 5850 28,49 2,88
VL606AN 907 795 326 343,0 5192 269,4 279738 279738 6700 6167 28,56 2,89
VL606N 909 796 327 359,6 5209 282,3 294669 294669 7041 6483 26,63 2,89
VL606K 907 795 326 369,3 5193 289,8 302124 302194 7236 6661 26,60 2,89
VL606KN 909 796 327 390,9 5125 306,9 321140 321140 7673 7063 26,66 2,89
VL628-1,5 927 806 332 363,6 5307 285,6 305611 305611 7143 6597 28,99 2,91
VL628AN 928 807 332 374,0 5318 293,7 315090 315090 7354 6794 29,03 2,94
VL628A 929 808 332 385,2 5329 302,4 325645 325645 7588 7012 29,08 2,95
VL628 929 809 332 389,0 5333 305,4 329063 329063 7664 7083 29,08 2,95
VL628K 930 809 333 395,6 5339 310,5 335179 335179 7799 7209 29,11 2,95
VL607A 921 806 330 406,0 5312 318,6 343170 343170 8004 7453 29,07 2,93
VL607 923 807 331 429,5 5334 337,2 364602 364602 8478 7898 29,14 2,92
VL607K 925 808 331 446,3 5351 350,4 380300 380300 8822 8223 29,19 2,94



spundbohle-produkte-spundbohlenfaehle-vierfachbox

Palancole

Scatola quadrupla

profilio Dimensioni Ambito Area peso Momento d’inerzia Momento resistente Raggio di curvatura minimo Superficie di rivestimento
Tavola singola Scatola
B H y-y z-z y-y z-z
mm mm cm cm2 cm2 kg/m cm4 cm4 cm3 cm3 cm m2/m
VL601 968 968 369 236,0 7027 185,2 258198 258198 5335 5335 33,08 3,20
VL601FP 968 968 369 241,6 7027 189,6 263945 263945 5454 5454 33,05 3,20
VL601K 969 969 369 247,0 7034 194,0 270384 270384 5582 5582 33,09 3,20
VL602A 970 970 369 261,5 7058 205,2 286438 286438 5905 5905 33,10 3,20
VL602 971 971 369 272,0 7068 213,6 298312 298312 6145 6145 33,12 3,21
VL602K 972 972 369 282,4 7079 221,6 310178 310178 6384 6384 33,14 3,21
VL603A 985 985 395 313,3 7530 246,0 364817 364817 7407 7407 34,12 3,45
VL603 986 986 397 327,1 7545 256,8 381896 381896 7744 7744 34,17 3,45
VL603KN 989 989 396 340,8 7583 267,6 398749 398749 8063 8063 34,21 3,46
VL603K 989 989 396 345,5 7583 271,2 404227 404227 8174 8174 34,20 3,46
VL603N 1088 1088 406 304,4 8063 238,8 383199 383199 7045 7045 35,48 3,53
VL603Z 993 993 398 367,4 7621 288,4 431074 431074 8684 8684 34,25 3,47
VL604A 1059 1059 421 362,0 8252 284,0 461491 461491 8718 8718 35,70 3,70
VL604 1059 1059 421 372,6 8257 292,4 475644 475644 8982 8982 35,73 3,71
VL604K 1060 1060 421 383,3 8266 300,8 490200 490200 9252 9252 35,76 3,71
VL605A 1089 1089 429 389,9 8495 306,0 514635 514635 9451 9451 36,33 3,79
VL605N 1092 1092 430 418,5 8523 328,4 557375 557375 10211 10211 36,49 3,80
VL605KN 1093 1093 431 436,2 8539 342,4 582398 582398 10656 10656 36,54 3,80
VL606A 1099 1099 432 435,2 8576 341,6 587726 587726 10695 10695 36,75 3,82
VL606AN 1101 1101 433 457,3 8598 359,2 620950 620950 11279 11279 36,85 3,82
VL606N 1103 1103 433 479,5 8620 376,4 654278 654278 11863 11863 36,94 3,83
VL606K 1101 1101 432 492,4 8599 386,4 672021 672021 12207 12207 36,94 3,82
VL606KN 1103 1103 433 521,2 8628 409,2 714235 714235 12950 12950 37,02 3,83
VL628-1,5 1122 1122 440 484,9 8752 380,8 674660 674660 12028 12028 37,30 3,90
VL628AN 1123 1123 440 498,6 8765 391,6 695661 695661 12389 12389 37,35 3,91
VL628A 1124 1124 441 513,7 8780 403,2 719058 719058 12790 12790 37,41 3,91
VL628 1125 1125 441 518,7 8785 407,2 726613 726613 12920 12920 37,43 3,91
VL628K 1126 1126 441 527,4 8794 414,0 740159 740159 13151 13151 37,46 3,91
VL607A 1124 1124 438 541,3 8757 424,8 759384 759384 13517 13517 37,46 3,88
VL607 1126 1126 439 572,6 8787 449,6 806845 806845 14329 14329 37,54 3,87
VL607K 1128 1128 440 595,1 8810 467,2 841559 841559 14919 14919 37,61 3,89

La massa del cordone di saldatura non è inclusa nel calcolo. Area di rivestimento esterna senza includere la superficie interna delle serrature.
